RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
8-10
Cleaning the Platen and Transfer Rollers
Step Procedure
1 Leave the Printer power ON and open the Lamination Arm.
If using a Printer with a Card Lamination Module attached, also open the
Lamination Module's Top Cover and Lamination Station.
2 Remove the Print Ribbon and HDP Film.
3 Locate the Print Platen Roller.
4 Use a Cleaning Pad from the Printer Cleaning Kit to wipe the Roller clean.
5 Locate the Transfer Platen Roller.
6
Danger: Transfer Rollers will be extremely hot. Printer must be cold
in order to clean it.
a. Use a Cleaning Pad from the Printer Cleaning Kit to wipe the Roller
clean. Press the Forward and Back buttons to move the Roller back and
forth while cleaning.
b. If using a Printer with a Card Lamination Module (attached), wipe the
Lamination Transfer Roller clean as well.
7 Replace the printing supplies and close the Print and Transfer Stations after
the Rollers are clean and completely dry.
