RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
10-5
Reviewing the Sensor Locations and Voltages
Sensor or Switch Location Low Range (VDC) High Range
(VDC)
Ribbon Supply Encoder
D860095
J4 pin 12 Unblocked (.17 or
lower)
Blocked 3.0 -
3.5
Print Head Lift Sensor
D860093
J4 pin 8 Unblocked (.17 or
lower)
Blocked 3.0 -
3.5
Card Position Sensor
D860111
J5 pin 4 Unblocked (.17 or
lower)
Blocked 3.0 -
3.5
Hopper Position Sensor
D860113
J8 pin 4 Unblocked (.17 or
lower)
Blocked 3.0 -
3.5
Film Supply Encoder
D860100
J10 pin 4 Unblocked (.17 or
lower)
Blocked 3.0 -
3.5
Transfer Head Lift Sensor
D860100
J10 pin 12 Unblocked (.17 or
lower)
Blocked 3.0 -
3.5
Ribbon Mark Sensor 1
D860112
J9 pin 9 Blocked (.8 or
lower)
Unblocked +4
Ribbon Mark Sensor 2
D860112
J9 pin 7 Blocked (.8 or
lower)
Unblocked +4
Ribbon Mark Sensor 3
D860112
J9 pin 11 Blocked (.8 or
lower)
Unblocked +4
Ribbon Mark Sensor 4
D860112
J9 pin 5 Blocked (.8 or
lower)
Unblocked +4
Continued on the next page
