RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
10-3
Resolving the DRAM Memory Error
Symptom: An error has occurred in the removable memory Module (SIMM). (Note: The
LCD will state the following: Main Memory Error.)
Step Procedure
1 Reboot the Printer.
2 If the problem persists, remove the rear cover and ensure that the SIMM
(080229) is seated properly.
3 If the memory Module is not seated properly, lock the SIMM into place.
4 If the installation appears correct and the error persists, the SIMM (080229)
on the Main Print Board will need to be replaced.
Resolving the RAM Memory Error
Symptom: An error has occurred in the permanent circuit memory.
Step Procedure
1 Reboot the Printer.
2 If the problem persists, replace the Main Print Board.
3 As an alternative to replacing the Main Print Board, the chip U22 may be
replaced. (Note: Fargo recommends that only a qualified electronics
technician perform this procedure.)
