Selecting the Card Size (HDP600 and HDP600-LC)
Step Procedure
1 Select the appropriate card option:
 CR-80: This selection is the default form size for the HDP600. This will
print a 2.125 X 3.374 image including a .04 over-bleed on each of the 4
sides making the overall form size 2.204 X 3.452 (56 X 87.7 mm).
 CR-80 No Over-Bleed: This selection eliminates the over-bleed on both
the leading and trailing edge making the form size of 2.2 X 3.374 (56 X
85.7 mm). Note: This selection is used to improve the overall readability
of barcodes.
 Custom: This selection is used to create a custom form size from 1.0 x
3.0 to 2.204 to 3.452 (25.4 X 76.2 mm to 56 X 87.7 mm).
