HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
1-6
Reviewing HDP 600 Series Card Printer - Sequence of Operations (continued)
Step
Process
23 The Film/Ribbon Drives and Print Platen Stepper turn ON to advance the printed
portion of the Film into position at the heated Lam Roller Stepper Motor, using the
Lamination Film Alignment Sensor.
24 The Headlift Motor engages, moving the Printhead up until the Headlift Sensor is
activated. All stop. (Note: This step is not performed after the last Color/Heat Seal
Panel is printed.)
25 If the heater is not at the required temperature yet, the job will pause.
26 Stepper engages to move the card to a position directly under the hot Roller. The
Top of Form Sensor determines card edge and number of steps to position card.
All stop.
27 The Headlift Motor turns ON to lower the hot Roller and will stop when the Headlift
Sensor is activated. All off.
28 The Stepper and Film Drive engage to laminate the printed Film onto the card.
They will turn off after a given number of steps based on the position given by the
card Sensor. All stop. (Note: The Film Encoder is active during this step.)
29 The Headlift Motor turns on to raise the hot Roller, stopping when the Headlift
Sensor is activated.
30 The Film Drive and Stepper turn ON for a given number of clicks based on Film
Encoder, until the film is released.
31 The Stepper turns ON to move the card into the Output Hopper (based on steps
from a known position). All stop.
32 The Heater and Thermocouple are maintained at a set temperature at all times
when the Printer is ON. The cooling fan is ON when the Printhead is ON or hot.
