RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
11-1
Section 11: LCD On-Line Menu
Navigation
Important: The procedures in this section apply for the HDP600/HDP600-LC and
HDP600 CR100/HDP600-LC CR100 card Printers.
The purpose of this section to provide the User with specific procedures for LCD On-Line
Menu Navigation, Test Image Printing and Printer Setup for the HDP600.
Entering the LCD Menu and selecting an Option
The MENU option is above the center softkey button, as shown below. This allows you to
access several test, setup and reporting functions. The Selecting from the Menu Option Tree
Structure shows the available menu options. A description of each option and its function is
included in this section following the on-line menu.
Step Procedure
1
Press the MENU button to bring up the Main Menu screen appears.
1 Use the scroll buttons to move up or down through the menu options, as shown
below. (Note: The brackets([ ]) appear on either side of the active Menu option.)
2
Press the button below Select to choose an option.
