RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
2-16
Printer Components: Resin Thermal Transfer to USB Interface Port (continued)
Component Description
Scroll Buttons Used to scroll through menus and sub-menus and to adjust certain
menu options.
Card Thickness
Adjustment
Lever
Adjusts the Printer to feed varying card thicknesses.
Card Cleaning
Assembly
Automatically cleans cards for higher print quality. (Note: Clean this
Assembly after every 1000+ cards or as needed.)
Power Switch Turns the Printer power ON and OFF.
Power Port Connect to the included power supply.
USB Interface
Port
Connect to the Windows PC USB cable.
