HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
106
Step
Procedure
3
Remove the retaining ring(140062) and washer (F000450)
Release the spring from the tab (D940254)
(continued next page)
