HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
14
Remove/Replace the Input Cover (D940092-02)
Tools needed: T10 Torx Driver, Philip driver
Estimated Time: 10 minutes
Important: This procedure can only be performed by authorized
service personnel.
**Remove this cover if replacing the Bezel LCD Display Assembly
(D940088-01)
Caution: Power off the Printer by unplugging the power cord from the Printer.
Remove (1) screw (F000190) from the bottom BACK cover. (T10 driver)
To Next Page
