HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
20
Remove/Replace the Door Cover (D940090-01)
Tools needed: T10 Torx Driver
Estimated Time: 10 minutes
Important: This procedure can only be performed by authorized service
personnel.
Caution: Power off the Printer by unplugging the power cord from the Printer.
Remove the (2) screws (F000170) from the left and right side hinges.
* When replacing the Door do not tighten this screw at this step.
To Next Page
