Step
Procedure
4
Remove (2) screws (F000231) from the bottom Output Trim Cover (D940202-02). (Philip
Driver)
* When replacing the Output Cover do not tighten this screw at this step.
5
Remove the Output Cover.
6
Reverse the instructions to re-assemble or install a new cover.
*Tighten all the screws after the cover is completely attached.
