Flipper Table Remove/Replace Procedures
In order to access the Flipper Module please remove the Rear/Top Cover, the Front Panel, and the
Output Cover.
Refer to the procedures for:
1. Top/Rear Cover D940089
2. Front Panel Cover D940201-01
3. Output Cover D940199-02
