Fargo HDP8500 - Page 112

HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
112
Step
Procedure
5
Replace it with the new Main Board.
6
Reconnect the cables.
Refer to Appendix A for Cable Connection diagram.
