HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
80
Step
Procedure
13
Disconnect the wires from the tie wrap on the Fan Box.
14
Disconnect the Ribbon Cable from the D000445 Board ( attached to the Fan Box Riser)
Set aside the Fan Box and Fan Box Riser.
