Fargo HDP8500 - Page 99

HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
99
Step
Procedure
Remove Covers
4
Remove 6 screws from the Rear cover (D940073-02).
Remove 5 screws from the Top cover.
Lift up and off frame
5
Remove 6 screws from the Rear cover (D940073-02).
6
Remove 5 screws from the Front cover (D940222-01)
