FARO
®
Laser Scanner Manual
133
Chapter 9: Maintenance
Figure 9-101: Folding the cleaning pad (2)
2. Repeatedly fold the cleaning pads in half as shown in the pictures above--
fold twice on the long side, then turn 90°, fold twice more to create a soft
pad that is about 30 mm long.
Figure 9-102: Fix the cleaning pad
3. Use the forceps to fix the cleaning pad as shown in picture. Leave at least
2-3 mm between the edge of the pad and the forceps.
