FARO
®
Laser Scanner Manual
22
Chapter 6: Getting Started
The FARO Laser Scanner need not be switched on to charge the battery.
6.1.2 Charging the Battery with the Power Dock Battery Charger
1. Connect the cable of the power supply unit to the power socket of the
FARO Power Dock battery charger. If you forcibly insert the plug in a wrong
direction, the plug and the Power Dock battery charger can be damaged.
Figure 6-11: Power Dock battery charger with connected power cable
2. Connect the AC power cable to the power supply unit as well as to a power
outlet. Check the input voltage on the type label before connecting.
3. The LED of the Power Dock battery charger illuminates blue when power is
connected correctly.
4. Place the battery on top of the Power Dock battery charger. Ensure that the
battery terminals are aligned correctly with the pins of the charger. Let the
battery snap into place.
DANGER
Do not operate the scanner while the external power
supply is plugged in, as the power cable might damage the
turning scanner.
Remove FARO Laser Scanner from the transport case before
connecting the power supply to the scanner.
Before prolonged storage, remove the power supply unit and
the battery from FARO Laser Scanner.
