FARO
®
Laser Scanner Manual
54
Chapter 7: Controller Software
Chapter 7: Controller Software
7.1 General Elements
7.1.1 Status Bar
Figure 7-33: Status Bar
Clock - shows the current time of the scanner. See Setting the Date and
Time
on page 35 for information on how to change the date and time of the
scanner.
SD card status
WLAN is turned on, and the signal strength is displayed.
GPS signal
Battery - shows the status and charge state of the internal battery:
SD card is busy.
Do not remove the SD card from the scanner while it is busy, otherwise you risk
corrupting the data on the card.
No SD card inserted.
SD card is write-protected. Remove write protection to be able to scan with this
card.
Unknown SD card inserted. The card cannot be read. This might be due to the
SD card being formatted in an unsupported file system. You should format the
SD card with the built in format function. See
SD Card on page 103.
GPS signal available.
No GPS signal, or vague position.
