Chapter 5: Parts and their Functions
Chapter 5: Parts and their Functions
5.1 Scanner Parts
5.1.1 Display Side
Figure 5-4: Display side of the FARO Laser Scanner
 Power On/Off button - Press this button to power on the FARO Laser
Scanner. If the scanner is on and running, press this button to power it
down. Pressing and holding the button more than 3 seconds will switch the
FARO Laser Scanner off without shutting down. Use this option only in
exceptional cases, for example, if the shutdown mechanism does not work
or the FARO Laser Scanner is non-responsive.
 Touch-screen display
 Electrical Interface 1
 Electrical Interface 2
The Electrical Interfaces 1 and 2 are not available in Focus
M
70. For details on the Electrical Interfaces of FARO Laser
Scanner Focus
S
70, Focus
S
150 and Focus
S
350 check the
related Automation Interface Manual.




