Chapter 7: Controller Software
7.2 Home Screen
Figure 7-37: Home Screen
Start Scan button - Starts a scan. See Starting a Scan on page 48.
Parameters button - Opens the dialog to select another scan profile and to
edit the current scanning parameters. For more information, see
Setting
the Scanning Parameters
on page 38.
Info box - Tap the arrow button underneath HOME to show or hide the info
box. The info box informs about the currently selected operator, project
and scan profile. It also shows information about the current scanning
parameters resolution in megapoints, quality, scan duration and color.
Add cluster button - Tap to add a cluster to the currently selected project.
View Scans button - Preview the scans that are stored on the SD card.
See
View Scans on page 109.
Manage button - Manage scan profiles, projects, operators and the
scanner. See
Manage on page 67.
