Fimer PVS980-58 - AC500 Module DO571 #1 (-A541); AC500 Module DO571 #2 (-A542); AC500 Module AI523-XC #1 (-A510); AC500 Module AI523-XC #2 (-A511)

Control unit 153
 AC500 module DO571 #1 (-A541)
Signal/parameter name Optional Interface type I/O terminal
M1 CHARGING CONTROL Relay out max. 240 V AC, 2 A RO0
M1 AC CONTACTOR CONTROL Relay out max. 240 V AC, 2 A RO1
M1 DC CONTACTOR CONTROL Relay out max. 240 V AC, 2 A RO2
M1 FAN CONTROL Relay out max. 240 V AC, 2 A RO3
M2 CHARGING CONTOL Relay out max. 240 V AC, 2 A RO4
M2 AC CONTACTOR CONTOL Relay out max. 240 V AC, 2 A RO5
M2 DC CONTACTOR CONTOL Relay out max. 240 V AC, 2 A RO6
M2 FAN CONTROL Relay out max. 240 V AC, 2 A RO7
 AC500 module DO571 #2 (-A542)
Signal/parameter name Optional Interface type I/O terminal
M1 AC BREAKER TRIP SET X Relay out max. 240 V AC, 2 A RO0
M1 AC BREAKER CLOSE CONTROL X Relay out max. 240 V AC, 2 A RO1
M1 AC BREAKER OPEN CONTROL X Relay out max. 240 V AC, 2 A RO2
SPARE RO X Relay out max. 240 V AC, 2 A RO3
M2 AC BREAKER TRIP SET X Relay out max. 240 V AC, 2 A RO4
M2 AC BREAKER CLOSE CONTROL X Relay out max. 240 V AC, 2 A RO5
M2 AC BREAKER OPEN CONTROL X Relay out max. 240 V AC, 2 A RO6
SPARE RO X Relay out max. 240 V AC, 2 A RO7
 AC500 module AI523-XC #1 (-A510)
Signal/parameter name Optional Interface type I/O terminal
SPARE AI Analog input ±10 V DC AI0
SPARE AI Analog input 4…20 mA AI1
SPARE AI Analog input 4…20 mA AI2
M1 LCL CABINET TEMPERATURE Analog input PT100 AI3
M1 AC CABINET TEMPERATURE Analog input PT100 AI4
SPARE AI Analog input PT100 AI5
USER AI1 Analog input 4…20 mA AI6
M1 MAIN AIR CHANNEL TEMP. Analog input PT100 AI7
SPARE AI Analog input ±10 V DC AI8
M2 DC CABINET HUMIDITY Analog input 4…20 mA AI9
SPARE AI Analog input 4…20 mA AI10
M2 LCL CABINET TEMPERATURE Analog input PT100 AI11
M2 AC CABINET TEMPERATURE Analog input PT100 AI12
SPARE AI Analog input PT100 AI13
USER AI2 Analog input 4…20 mA AI14
SPARE AI Analog input PT100 AI15
 AC500 module AI523-XC #2 (-A511)
Signal/parameter name Optional Interface type I/O terminal
M1 DC CURRENT 1 MEASUREMENT X Analog input ±10 V DC AI0
M1 DC CURRENT 2 MEASUREMENT X Analog input ±10 V DC AI1
M1 DC CURRENT 3 MEASUREMENT X Analog input ±10 V DC AI2
M1 DC CURRENT 4 MEASUREMENT X Analog input ±10 V DC AI3
