Fimer PVS980-58 - DC Input Connection Data

104 Technical data
Overvoltage category
(IEC 62109-1, IEC 60664-1)
For output mains and 3-phase customer aux.: 3
For 1-phase service outlet: 2
Integrated surge protection Type 2 as standard, Type 1 (fulfilling also Type 2) available as option (+F263)
Harmonic distortion THD current < 3% at nominal power
DC input connection data
Maximum DC power (P
pv
) Refer to Ratings on page 94.
Maximum DC current
(I
max(DC)
)
Refer to Ratings on page 94.
Maximum DC operational
voltage (U
max(DC)
)
1500 V DC
DC voltage range with
nominal output power at
35 °C, U
mppt, 35 °C
PVS980-58-1818kVA-I: 850…1500 V DC
PVS980-58-1909kVA-J: 893…1500 V DC
PVS980-58-2000kVA-K: 935…1500 V DC
PVS980-58-2091kVA-L: 978…1500 V DC
DC voltage range with
nominal output power at
50 °C, U
mppt, 50°C
PVS980-58-1818kVA-I: 850…1100 V DC
PVS980-58-1909kVA-J: 893…1100 V DC
PVS980-58-2000kVA-K: 935…1100 V DC
PVS980-58-2091kVA-L: 978…1100 V DC
Voltage ripple < 3%
Overvoltage category
(IEC 62109, IEC 60664-1)
2
Integrated surge protection Type 2 as standard, Type 1 (fulfilling also Type 2) available as option (+F300)
DC short-circuit withstand
strength
4 kA (10 kA with option F317)
Allowed electrical system Negative pole functionally grounded as standard, positive pole functional
grounding and floating DC available as options (+F282, +F314)
Maximum backfeed current
(current coming from
inverter capacitor bank in
case of a short circuit on DC
input)
8 inputs: peak 30 kA, 3 cycles (average) 1900 A, duration 600 µs
12 inputs: peak 24 kA, 3 cycles (average) 1900 A, duration 600 µs
16 inputs: peak 22 kA, 3 cycles (average) 1900 A, duration 600 µs
20 inputs: peak 20 kA, 3 cycles (average) 1900 A, duration 600 µs
24 inputs: peak 18 kA, 3 cycles (average) 1900 A, duration 600 µs
