Fimer PVS980-58 - Fuses

98 Technical data
Fuses
Note: Max I
SC, PV
is based on the short-circuit current withstand strength of the
inverter, and is higher than the default fuse rating. This enables a higher DC/AC
ratio, but pay special attention to the fuse configuration when you over dimension.
PVS980-58-
1818kVA-I
PVS980-58-
1909kVA-J
PVS980-58-
2000kVA-K
PVS980-58-
2019kVA-L
DC
DC input fuses - 8 DC inputs (8H382) Bussmann PV-400A-3L-B-15
• Nominal current (I
N
) 400 A
• Quantity 8 (negative polarity functionally grounded and without fuses),
16 with the floating DC option (+F314)
• Max I
SC, PV
500 A (1000 A with option +F317)
DC input fuses - 12 DC inputs (12H382) Bussmann PV-400A-3L-B-15
• Nominal current (I
N
) 400 A
• Quantity 12 (negative polarity functionally grounded and without fuses),
24 with the floating DC option (+F314)
• Max I
SC, PV
333 A (667 A with option +F317)
DC input fuses - 16 DC inputs (16H382) Bussmann PV-400A-3L-B-15
• Nominal current (I
N
) 400 A
• Quantity 16 (negative polarity functionally grounded and without fuses),
32 with the floating DC option (+F314)
• Max I
SC, PV
250 A (500 A with option +F317)
DC input fuses - 20 DC inputs (20H382) Bussmann PV-250A-2XL-B-15
• Nominal current (I
N
) 250 A
• Quantity 20 (negative polarity functionally grounded and without fuses),
40 with the floating DC option (+F314)
• Max I
SC, PV
200 A (400 A with option +F317)
DC input fuses - 24 DC inputs (24H382) Bussmann PV-200A-1XL-B-15
• Nominal current (I
N
) 200 A
• Quantity 24 (negative polarity functionally grounded and without fuses),
48 with the floating DC option (+F314)
• Max I
SC, PV
167 A (333 A with option +F317)
AC
AC fuse 170M6466
• Nominal current (I
N
) 1250 A
• Quantity 6
