Fimer PVS980-58 - Default I;O Connection Table; A41); AC500 Module PM564 (-A500)

150 Control unit
Default I/O connection table
The default I/O connections of the BCU-12 control unit and the AC500 modules.
 BCU-12 (-A41)
Signal/parameter name Optional Interface type I/O terminal
INSULATION MONITORING
MEASUREMENT
Analog input 4…20 mA AI1
GROUNDING CURRENT
MEASUREMENT
(X) Analog input 4…20 mA AI2
M1 CABINET FAN SPEED REFERENCE Analog output 4…20 mA AO1
M2 CABINET FAN SPEED REFERENCE Analog output 4…20 mA AO2
RUN/STOP STATUS Digital input 24 V DC DI1
FAST POWER OFF Digital input 24 V DC DI2
DC GROUNDING STATUS (X) Digital input 24 V DC DI3
24V BUFFER ACTIVE STATUS Digital input 24 V DC DI4
M1 AUX. PROTECTION DEVICES
STATUS
X Digital input 24 V DC DI5
SPARE DI Digital input 24 V DC DI6
M2 AUX. PROTECTION DEVICES
STATUS
Digital input/output 24 V DC DIO1
SPARE DIO Digital input/output 24 V DC DIO2
CONTACTOR CONTROL DUPLICATION Relay output max. 240 V AC, 2 A RO1
GROUNDING CONTROL (X) Relay output max. 240 V AC, 2 A RO2
INSULATION MONITORING CONTROL Relay output max. 240 V AC, 2 A RO3
 AC500 module PM564 (-A500)
Signal/parameter name Optional Interface type I/O terminal
MAIN CIRCUIT SPD STATUS Digital input 24 V DC DI0
SMOKE DETECTOR STATUS X Digital input 24 V DC DI1
USER DI1 Digital input 24 V DC DI2
USER DI2 Digital input 24 V DC DI3
USER DI3 Digital input 24 V DC DI4
USER DI4 Digital input 24 V DC DI5
CONTROL SECTION HUMIDITY Analog input 0…10 V DC AI0
SPARE AI Analog input 0…10 V DC AI1
SPARE AO Analog output 4…20 mA AOI
STATUS LAMP GREEN Relay out max. 240 VAC, 2A RO0
STATUS LAMP YELLOW Relay out max. 240 VAC, 2A RO1
STATUS LAMP RED Relay out max. 240 VAC, 2A RO2
CABINET HEATING X Relay out max. 240 VAC, 2A RO3
SPARE RO Relay out max. 240 VAC, 2A RO4
USER RO1 Relay out max. 240 VAC, 2A RO5
