Inverter power module label
The type designation label of the inverter power module includes the ratings, certification
marks, type designation and serial number. The inverter power module label is attached to
the front panel of the inverter module.
FRAME
R35iSC
160 kg
Input
Output
Code
Udc
Uac
Imax
Imax
Smax
3AUA0000185195
S/N:9185100555
PVS980-104SC-875A-7
650...1500 VDC
3 ~ 500...690 VAC
1230 A
926 A
50/60 HZ
1150 k VA
~
f
f
IP00
UL open type
Air cooling
MADE IN INDIA
FIMER S.p.A
Via J.F Kennedy 26
20871 Vimercate (MB)
Italy
No. Description
1. Type designation, refer to Type designation key on page 44.
2. Frame size
3. Degree of protection
4. Ratings of the inverter module
5. Valid certification marks
6. Serial number. The first digit of the serial number refers to the manufacturing plant. The next four
digits refer to the unit’s manufacturing year and week, respectively. The remaining digits are unique
to the unit.
6
1
5
4
2
3
