Control unit 145
 ABB AI561
No. Description
1. I/O bus
2. 1 green LED shows power supply status
3. 1 red LED shows errors
4. Terminal number
5. Allocation of signal name
6. Terminal block for input signals (20-pole)
7. DIN rail
