Fimer PVS980-58 - AC500 Module AI523 #1 (-A510); AC500 Module AI523 #2 (-A511); AC500 Module AI561 #1 (-A520)

Control unit 151
 AC500 module AI523 #1 (-A510)
Signal/parameter name Optional Interface type I/O terminal
SPARE AI Analog input ±10 V DC AI0
SPARE AI Analog input 4…20 mA AI1
SPARE AI Analog input 4…20 mA AI2
M1 LCL CABINET TEMPERATURE Analog input PT100 AI3
M1 AC CABINET TEMPERATURE Analog input PT100 AI4
SPARE AI Analog input PT100 AI5
SPARE AI Analog input PT100 AI6
M1 MAIN AIR CHANNEL
TEMPERATURE
Analog input PT100 AI7
SPARE AI Analog input ±10 V DC AI8
M2 DC CABINET HUMIDITY Analog input 4…20 mA AI9
SPARE AI Analog input 4…20 mA AI10
M2 LCL CABINET TEMPERATURE Analog input PT100 AI11
M2 AC CABINET TEMPERATURE Analog input PT100 AI12
SPARE AI Analog input PT100 AI13
USER AI1 Analog input 4…20 mA AI14
USER AI2 Analog input 4…20 mA AI15
 AC500 module AI523 #2 (-A511)
Signal/parameter name Optional Interface type I/O terminal
M1 DC INPUT CURRENT 1 MEAS. X Analog input ±10 V DC AI0
M1 DC INPUT CURRENT 2 MEAS. X Analog input ±10 V DC AI1
M1 DC INPUT CURRENT 3 MEAS. X Analog input ±10 V DC AI2
M1 DC INPUT CURRENT 4 MEAS. X Analog input ±10 V DC AI3
M1 DC INPUT CURRENT 5 MEAS. X Analog input ±10 V DC AI4
M1 DC INPUT CURRENT 6 MEAS. X Analog input ±10 V DC AI5
M1 DC INPUT CURRENT 7 MEAS. X Analog input ±10 V DC AI6
M1 DC INPUT CURRENT 8 MEAS. X Analog input ±10 V DC AI7
M2 DC INPUT CURRENT 1 MEAS. X Analog input ±10 V DC AI8
M2 DC INPUT CURRENT 2 MEAS. X Analog input ±10 V DC AI9
M2 DC INPUT CURRENT 3 MEAS. X Analog input ±10 V DC AI10
M2 DC INPUT CURRENT 4 MEAS. X Analog input ±10 V DC AI11
M2 DC INPUT CURRENT 5 MEAS. X Analog input ±10 V DC AI12
M2 DC INPUT CURRENT 6 MEAS. X Analog input ±10 V DC AI13
M2 DC INPUT CURRENT 7 MEAS. X Analog input ±10 V DC AI14
M2 DC INPUT CURRENT 8 MEAS. X Analog input ±10 V DC AI15
 AC500 module AI561 #1 (-A520)
Signal/parameter name Optional Interface type I/O terminal
M1 DC INPUT CURRENT 9 MEAS. X Analog input ±5 V DC AI0
M1 DC INPUT CURRENT 10 MEAS. X Analog input ±5 V DC AI1
M1 DC INPUT CURRENT 11 MEAS. X Analog input ±5 V DC AI2
M1 DC INPUT CURRENT 12 MEAS. X Analog input ±5 V DC AI3
