Control unit 147
 ABB DO571
No. Description
1. I/O bus
2. 8 yellow LEDs show the signal state of outputs
O0...O7
3. Terminal number
4. Allocation of the signal name
5. Terminal block for output signals (11-pole)
6. 2 holes for wall mounting with screws
7. DIN rail
1
2
3
4
5
6
7
6
