146 Control unit
 ABB DI562
No. Description
1. I/O bus
2. 16 yellow LEDs show the signal state of inputs
I0...I15
3. Terminal number
4. Allocation of signal name
5. Terminal block for input signals (9-pole)
6. Terminal block for input signals (11-pole)
7. 2 holes for wall-mounting with screws
8. DIN rail
1
2
3
4
5
6
7
8
7
