Operation
CM-3202-11-I Installation and User Guide Revision 100
This document does not contain any export-controlled information.
Figure 38: OSD Page - OSD1 Settings
Click OSD1, OSD2, or Event.
Enable (not available when configuring Event OSD settings):
o Device Name: The device name appears on-screen. Users assigned the role of admin or expert
can configure the device name on the Firmware & Info Page
.
o Date: The date appears on-screen.
o Text: The time appears on-screen.
o OFF (default): Disables OSD.
Background Color: Black or Transparent (default).
Text Color: Black or White (default).
Location X: Determines the horizontal location of the OSD. Specify a value between 1 (far left; default)
and 10 (far right).
Location Y: Determines the vertical location of the OSD. Specify a value between 1 (top; default) and 10
(bottom).
4.8 Privacy Zone Page
Privacy zones cover a configurable portion of the screen for privacy reasons. You can define up to eight
privacy zones. After setting up a privacy zone, it appears in the Live View window and in the video
streams as a solid area with a configurable color, size, and position.
