Configuration
CM-3202-11-I Installation and User Guide Revision 100
June 2020
54
This document does not contain any export-controlled information.
6. Click Next. The rule configuration Action screen appears.
Figure 62: Rule Configuration Action Screen
7. By default, for a new rule, action for the rule is enabled. To disable action for the rule, move the
slider to the left. This setting overrides any specific action setting.
8. By default, no specific actions are enabled. You can enable one or more of the following actions
when the trigger event occurs by moving the relevant slider to the right:
Alarm Out: Changes the state of the camera’s alarm output. You can configure the camera’s
alarm output on the I/O Page
.
Audio: The Sound (audio file) selected, between 1-10, is played through the camera’s audio
output. You can upload audio files for the sounds on the Sound Page
.
Snapshot: Stores one or more photo snapshots. You can enable:
o Store on Edge: Stores the snapshot(s) on the camera’s microSDXC card. If enabled,
make sure a microSD card is properly installed and formatted. See SD Card Page
.
o Store to FTP: Stores the snapshot(s) on the remote FTP server specified on the FTP
Page.
Recording: Records a video clip on the camera’s microSDXC card. You can configure the
camera’s recording settings on the Recording Page
.
Email: Sends an email using the settings on the Email Page. Specify a Subject and Message for
the email.
OSD: Displays the Text specified in the camera’s video stream and in the Live View window.
9. Click Done. The new rule appears in the list of Rules.
You can also modify or delete existing rules.
Figure 63: Rule List
