Configuration
CM-3202-11-I Installation and User Guide Revision 100
This document does not contain any export-controlled information.
SNMP v1
To enable SNMP v1, move the slider to the right. By default, SNMP v1 is disabled.
SNMP v2c
To enable SNMP v2c, move the slider to the right. By default, SNMP v1 is disabled.
Read Community String: Specify the community name that has read-only access to all supported SNMP
objects. The default value is public.
Write Community String: Specify the community name that has read/write access to all supported SNMP
objects (except read-only objects). The default value is private.
Trap Community String: Specify the community to use when sending a trap message to the
management system. The default value is public. Traps are used by the camera to send messages to
the management system for important events or status changes.
SNMP v3
To enable SNMP v3, move the slider to the right. By default, SNMP v1 is disabled.
User Name: Specify the user name. The default is initial.
Authentication Mode: Select MD5, SHA, or NONE (default).
Authentication Password (available when Authentication Mode is set to MD5 or SHA): Specify the
password for authentication.
Privacy Mode (available when Authentication Mode is set to MD5 or SHA): Select AES, DES, or NONE
(default).
Privacy Password (available when Privacy Mode is set to AES or DES): Specify the privacy password.
Trap
Mode: Select V1, V2C, V3, or OFF (default), according to the SNMP version that you enabled.
Target IP: Specify the IP address of the Trap Host.
Heartbeat: Sends SNMP notifications at regular intervals to detect network delays. To enable it, move
the slider to the right. By default, Heartbeat is disabled.
Heartbeat Interval (5-600): Specify the interval in seconds for the camera to send heartbeat notifications.
The default is 30 seconds.
Event: Automatically records the log file of events, for later review. To enable it, move the slider to the
right. By default, Event is disabled.
Download MIB
You can download the camera’s MIB (Management Information Base), which describes the structure of
the management data of the camera’s subsystem using a hierarchical namespace containing object
identifiers (OIDs). Each OID identifies a variable that can be read or set via SNMP.
Click Download. The database is downloaded.
5.14.3 802.1X
802.1X settings enable the camera to access a network protected by the 802.1X/EAPOL (Extensible
Authentication Protocol over LAN) authentication protocol.
