Configuration
CM-3202-11-I Installation and User Guide Revision 100
June 2020
55
This document does not contain any export-controlled information.
To modify an existing rule
1. In the list of rules, click the icon next to the rule. The rule trigger appears.
Figure 64: Rule List - Rule Trigger
2. Click the trigger. The rule configuration Trigger screen appears.
3. Modify the rule according to the procedure for creating an alarm rule
.
4. Click Done.
5.8 Audio Page
On the Audio page, you can configure the camera’s audio input and output settings.
Figure 65: Audio Page
Audio is enabled by default. To disable it, move the slider to the left. The setting applies to audio input
and output.
Line In
Level: Select High, Mid (default), or Low.
Encoding: Select AAC (default), G.711 a-law, or G.711 µ-law.
Line Out
Level: Select High, Mid (default), or Low.
To apply any changes to the settings, click Save.
5.9 I/O Devices Page
On the I/O Devices page, you can enable or disable all dry contacts, configure the number of input and
output pins, and enable or disable individual pins.
