FlyThisSim TouchTrainer® Set-up Guide
Copyright FlyThisSim LLC 2013 Page 11
2) Flip your TouchTrainer® base over and take note of where the cable harnesses are (Figure 5).
Figure 5: Topside of TouchTrainer® Base
MAIN Monitor
Harness
Computer
Harness
AUX Monitor
Harness
Joystick
Harness
Computer
Harness
