FlyThisSim TouchTrainer® Set-up Guide

Diamond G1000 Startup Procedure

Follow the guide step-by-step, pressing the button that matches the corresponding step in the procedure (i.e. press the

button labeled “1” in the picture below when working on step 1).

Note: Because the button layouts are not exactly the same across all systems, the following pictures may not match your

layout. The correct buttons will still be available, just not necessarily as shown in the pictures.

1) Turn on the master and alternator switches by touching the top half of each switch.

2) Turn on the avionics bus by touching the top half of the avionics switch.

Figure 56: Diamond G1000 Panel with no power

3) Press the rightmost softkey on the MFD to continue the MFD bootup.

Figure 57: Diamond G1000 Panel after MFD bootup
