76
20.1 Input the Start Station
1. Press F2: [MENU] on P2 of the basic measurement
mode, on the page 3 select 1.Road Calculation enter
road menu.
2. Select 1.Input the parameter to enter road design
menu. And then select 1.Horizontal Curve, start
point entering menu will display.
3.
Enter the start point station and coordinate, press
F4:[OK] key. Road horizontal elements editing menu
will display.
20.2 Input Road Horizontal Elements
Three types elements can be input, including line, curve and spiral.
20.2.1 Input Line Element
1. Make sure the instrument is in horizontal elements
editing menu, press F2 to display line element
inputting menu.
Input the line length and azimuth in the Dist and
Azimuth filed.
Press F4:[ENT] key to confirm.
Road Calculation
1.Input the parameter
2.Road Setout
3.Road file
Road Define
1.Horizontal Curve
2.Vertical curve
3.Road Calculation
HCurve/Start Point
STATION: 0.000
Np : 0.000
Ep : 0.000
Zp : 0.000
0OK0
Type EndPile
DELv LINEv CIR CURV
Line Input/LENGTH
Dist 100m
Azimuth 0°00′00″
ENDP ENT
