Foif RTS680 Series User Manual

87
20.6 Road Stake Out
1. Press F2: [MENU] on P2 of the basic measurement
mode, on the page 3 select 1.Road Calculation enter
road menu.
2. Select 2.Road Setout to road setout menu.
At road setout menu select 2.Road file to road setout
menu, select 1.Occ.Orientation to set the station and
backsight.
3. Select 2.RoadSetout to stake out road, the first
center station of road will display.
Here:
PT#: Station serial number
Code: Station mileage, “C” means center station, “R”
means right station, “L” means left station.
Press F1:[READ] key to open the station list.
Press F2:[PREV] key to display previous station..
Press F2:[NEXT] key to display next station.
4. Press F4:[ENT] to enter coordinate staking out
screen, see chapter “7.2 Coordinates Stake out
Measurement” to do that.
Road RoadCoordSO
Pt# 1
Code 0.000C
Np : 0.000
Ep : 0.000
Zp : 600.000
READ PREV NEXT ENT
Road Calculation
1.Input the parameter
2.Road Setout
3.Road file
Road Setout
1.Occ.Orientation
2.Road Setout
3.Road data view
Road RoadCoordSO
Pt# 1
Code 0.000C
Np : 0.000
Ep : 0.000
Zp : 600.000
READ PREV NEXT ENT
