Foif RTS680 Series User Manual

64
15. Traverse Surveying
Measure the coordinate of foresight point and save it in the list, this point would be taken
as the occupied point after transferring to point 2, and the previous occupied point will be
taken as the backsight point, the azimuth angle will be calculated and set.
15.1 Save Coordinate
Here is the operation of how to measure the foresight point and save it in the list.
【Procedure of saving coordinate】
1. Press F2: [
MENU] on P2 of the basic measurement
mode.
2. Turn to P2, select “
3.Traverse”.
3. Press “
1.Save coord”.
Meas PC 0
ppm 0
SD 33.417ft
VA 300.9994gon I
HA 44.6568gon P2
MENU HOLD HSET E D M
Menu P2
1.Point projection
2.Line stakeout
3.Traverse
4.Inverse
5.Polarize
Traverse
1.Save coord
2.Read coord
(0,0,0)
N
E
Occupied point P0
Azimuth
Known point A
P1
P2
P3
