Foif RTS680 Series User Manual

86
20.5 Road Staking Out Data View
After design and calculate the road, all the staking points can be view.
1. Press F2: [
MENU] on P2 of the basic measurement
mode, on the page 3 select 1.Road Calculation enter
road menu.
2. Select 2.Road Setout to road setout menu.
3. Select 3.Road data view to view the staking
station data, the station list will display.
Here:
STAKE: Center station serial number
RSTAKE: Right station serial number
LSTAKE: Left station serial number
Press F1:[
↑↓.P] key to change the function of ▲
and ▼ keys, if it is light, press ▲ or▼ to move
cursor between adjacent points. If it is backlight
display, press▲ or ▼ key to move cursor to display
adjacent pages.
Press F2:[TOP] key to move cursor to first station.
Press F3:[LAST] key to move cursor to last station
Press F4:[SRCH] key to enter the serial number(PT#)
to look for the station.
4. Press F4:[ENT] to display the coordinate of
selected station.
PT#: Station serial number
Code: Station mileage, “C” means center station, “R”
means right station, “L” means left station.
Press F1:[NEXT] key to display next station.
Press F2:[PREV] key to display previous station.
STAKE 1
STAKE 2
STAKE 3
STAKE 4
STAKE 5
STAKE 6
STAKE 7
↑↓.P TOP LAST SRCH
Road Calculation
1.Input the parameter
2.Road Setout
3.Road file
Road Setout
1.Occ.Orientation
2.Road Setout
3.Road data view
Road RoadCoordSO
Pt# 1
Code 0.000C
Np : 0.000
Ep : 0.000
Zp : 600.000
READ PREV NEXT ENT
Np : 0.000
Ep : 0.000
Zp : 600.000
Pt# 1
Code 0.000C
NEXT PREV
