5. Once the Pt# is the same as an existed one, it will
display as shown left:
Press F3: [
NO] to re-input;
Press F4: [
YES] to overwrite;
Press F1: [
ADD] to save, and the original one will
not be deleted.
23.2 Input Known Point Coordinate via RS-232C
【Procedure of Inputting known points coordinate】
1. Connect instrument and PC via RS-232C
communication cable. Press F3: [
MEM] in the status
mode to enter into memory management.
2. Select “2.Known data” , job list will display.
Select one Job you want to operate, press [ENT] key
to confirm, known data menu will display, you can
see the active JOB on the second line..
3. Select “
2.Com input”.
4. Run FOIFExchange software PC, see the help file
of FOIFExchagne to upload known data to current
JOB, the chapter is “2.1.2 Upload Known data from
PC to TS680 internal memory”.
When data transferring, the number following
Receiving will upgrade continually, at last it will back
to known data mode after finishing.
JOB6 Free 45911
Pt# S1 S1
N 10.500
E 11.544
Z 100.000
Overwrite?
ADD 0NO0 YES
Memory
1.JOB
2.Known data
3.Code
4.Storage Media Select
5.USB
JOB selection P1
DAFENG 10
JOBFF 3000
WOMENSHI 1256
FATELU 100
KEMEN 560
JOB6 0
JOB7 0
Com input
Receiving 0
Known data
JOB JOB6
1.Key input
2.Com input
3.Delete
4.View
5.Clear
6.Com setting
To Next Page
