3.8.3 Communication Port Setting
Please set communication parameters before connecting your computer.
1. Press key {
Cnfg} to enter into config mode.
2. Select “
4.Com setting” to set the parameters of
communication port.
3. Change the settings if necessary. Press keys { }/
{ } to select items and press keys { } / { } to set
the options.
4. Press key {
ESC} back to the previous mode.
Table 3-3 Option list of com setting
Item
Options
1.Baud rate 1200﹡/2400/4800/9600/19200/38400
2.Data bits 8bit﹡/ 7 bit
3.Parity No﹡/ Even/ Odd
4.Stop bit 1bit﹡/ 2bit
5.Check sum No﹡/ Yes
6.Xon/Xoff No﹡/ Yes
7.Com mode RS-232/B-TOOTH
Note:
◆ Every first options with the symbol “﹡” are the factory setting.
Config
1.Meas condition
2.Inst config
3.Inst adjust
4.Com setting
5.Unit
6.Date & Time
7.Key Function
Com setting
1.Baud rate
2.Data bits
3.Parity
4.Stop bit
5.Check sum
6.Xon/Xoff
7.Comode :B-TOOTH
:1200
:8bit
:No
:1bit
:No
:No
