4.2 Set the Horizontal Angle to a Required Value
1. Take your instrument sight the 1
st
target.
Press F4: [
HSET] at P2 in the measure mode.
2. Select the first item 1.Azimuth, and input the
required value in Azimuth filed, then press {
ENT} to
save the value. And it displays as the horizontal
angle.
The range and format of the input value:
gon: 0~399.9999
degree: 0 ~359.5959
mil: 0~6399.990
3. Sight the 2
nd
target. The horizontal angle from the
2
nd
target to the value set as the horizontal angle is
displayed.
NOTE: Pressing [
HOLD] performs the same
function as above. The horizontal angle is in hold
status when [
HOLD] is flashing, press [HOLD]
again to releasse the hold status.
Meas PC 0
ppm 0
SD
VA 302.5432gon II
HA 399.9998gon P1
CORD MENU HOLD H S E T
Set H Angle
1. Azimuth
2. Back sight
Set H Angle
Azimuth -399.9998
Tgt.H 0.000m
PT#
Observe point!
OK
Meas PC 0.0
ppm 0
SD
VA 302.5432gon II
HA 0.0000gon P2
CORD MENU HOLD H S E T
