3. Press F4: [MEAS] to re-measure distance or press
F1: [
OK], the measured data is set as“Pt-01”.
4. Repeat steps 2 and 3 till all points are measured one
by one. Make sure measure them clockwise or
anticlockwise. Press F2: [
CALC] and the calculated
area will display.
5. Press F4: [
OK] back to menu mode.
8.2 Area Calculation by Reading Existed Coordinates
【Procedure of area calculation】
1. Select F2: [
MENU]/ 3. Area /2.Area.
.
2. Press F1: [READ] to display existed coordinates
data list.
N 10.000
E 5.000
Z 53.493
VA 152.6296gon
HA 62.1314gon
0OK0 MEAS
01:Pt_01
02:Pt_02
03:Pt_03
04:Pt_04
05:
06:
07:
CALC MEAS
Area Calculation
Pt: 4
Area m2
ha
0OK0
Menu P1
1.Coordinate
2.Stakeout
3.Area
4.Offset
5.MLM
6.REM
7.Resection
01:
02:
03:
04:
05:
06:
07:
READ MEAS
