Foif RTS680 Series - EDM Setting

25
Key Resume
1. Press key {1} to resume the User Define 1 as the
current Key setting
2. Press key {2} to resume the User Define 2 as the
current Key setting
3. Press key {3} to resume the Default Define as the
current Key setting
3.8.6 EDM Setting
1. Press F1: [MEAS] in the status mode or select to
enter into measure mode.
Press key {
Func} to turn to page P3.
2. Press F1: [
EDM] to enter into EDM setting.
3. Change the settings if necessary. Press keys { }/
{ } to select the first three items and press keys { }
/ { } to set the options.
4. Press key {
ESC} back to the previous mode.
Table 3-5 EDM setting
Item
Options
1.Mode Fine “r”﹡/ FineAVG 3 / Fine “s” / Rapid “s” / Tracking
2.Reflector Prism﹡/ Sheet/ No prism
3.Prism const -99~99
4.Temp. -30～60℃(20℃﹡)/-22～140℉
5.Pressure 500～1400hPa(1013hPa﹡);
375～1050mmHg(760mmHg﹡);
14.8～41.3 inchHg (29.9inchHg﹡)
500～1400mbar(1013mbar﹡);
7.2～20.3Psi(14.7Psi﹡)
6.ppm -499～499(0﹡),
Press F1: [
0PPM] to set temperature, pressure and ppm as
factory setting.
KEY FUNCTION RESUME
1.User Define 1
2.User Define 2
3.Default Define
EDM
Mode
Reflector
Prism const
Temp.
Pressure
ppm
0PPM
:Fine “r”
:Prism
:0
:20℃
:1013hPa
:0
Meas PC 0.0
ppm 0
SD
VA II
HA P1
EDM OCC OFST R E C
