Foif RTS680 Series User Manual

83
20.4 Road Calculation
20.4.1 Input the road width element
1. Make sure the instrument is in Road Define menu,
select 3.Road Calculation
2. Press F1:[WIDE] to road width setting menu.
Press F1:[FIST] key, the cursor will move to the first
element.
Press F2:[LAST] key, the cursor will move to the last
element.
Press F3:[Del] key to delete the selected element.
Press F4:[ADD] key to add a new vertical element.
3. Press F4:[ADD] to enter road wide inputting menu.
4. Input the parameters of road width.
STATION: the road will take this width begin from
this point to next road width element
Lwide: left width
Rwide: right width
Press F4:[ENT] key to confirm.
5.Repeat step 4 to input other road width.
6. Press [ESC] back to road calculation menu.
SPile LW
FIST LAST DEL ADD
RoadCal/Calc
STATION:0.000
SPAC 0.000 m
WIDE PEG ENT
Road Define
1.Horizontal Curve
2.Vertical curve
3.Road Calculation
Wide Input
STATION: 0.000m
Lwide 3.000m
Rwide 4.000m
ENT
SPile LW
0.000 3.000
100.000 5.000
300.000 6.000
FIST LAST DEL ADD
RoadCal/Calc
STATION:0.000
SPAC 0.000 m
WIDE PEG ENT
