72
Input the length and offline to define a point
F1: measuring distance to confirm the position of stake out point
F2: stake out next point
F4: record current measured coordinate
E.A mode:
Input the arc length and offline to define some points position
F1: measuring distance to confirm the position of stake out point
F2: stake out next point
F3: stake out previous point
F4: record current measured coordinate
E.S mode
Input the chord length and offline to define some points position
F1: measuring distance to confirm the position of stake out point
F2: stake out next point
F3: stake out previous point
F4: record current measured coordinate
6. At Step 4, press F4:[MEAS] to measure the target,
the length and offset between the arc and measured
point will be displayed.
↓ ↑: Distance from measured point to arc, which is on
the telescope objective direction
: Height difference between measured point and
projective point on arc
Length: Following arc direction, distance from arc start point to projective point
Ofline: Shortest distance between measured point and arc, that is the distance on the
perpendicular line from measured points to projective point on the arc.
Are define/Input
Arc 10.000m
OfLine 5.000m
S. O E.S OK
↑
3.562m
→ 5.633m
▼ 0.487m
S-O Dhd
S-O Dha→ 12°31′26″
VA 60°15′49″
HA 355°38′27″
MEAS PT+ PT- REC
Are define/Input
string 10.000m
OfLine 5.000m
S. O E.A OK
↑
3.562m
→ 5.633m
▼ 0.487m
S-O Dhd
S-O Dha→ 12°31′26″
VA 60°15′49″
HA 355°38′27″
MEAS PT+ PT- REC
↑ 3.562m
▼ 0.487m
Length 2.026m
Ofline 2.927m
VA 71°43′49″
HA 26°17′27″
MEAS OK
