5. Distance Measurement
Please set the following items before distance measurement：
● Measurement condition ( See §3.8.1 Measure Condition Setting)
● EDM (See §3.8.6 EDM setting )
【Procedure of distance measurement】
1. Aim at the target, press F3:[
SHV2], the display
mode of basic measurement will change to SD/HD/VD
mode, and then press F1: [
DIST] to start measure
distance.
2. The symbol “*” moves continually when measuring
distance. Distance measuring mode, prism const and
ppm value are also presented.
3. Press F4: [
STOP] to finish measurement. The
“SD”,”HD”, and”VD” will display as shown left.
4. Press F3: [SHV2], SD/HD/VD and SD/VA/HA are
displayed alternatively.
Dist
Fine ppm 0
-----※ STOP
Meas PC 0
ppm 0
SD
HD II
VD P1
DIST S H V 1 SHV2 0SET
Meas PC 0
ppm 0
SD 10.329m
HD 7.009m II
VD 7.586m P1
DIST S H V 1 SHV2 0SET
Meas PC 0
ppm 0
SD 10.329m
HD 7.009m II
VD 7.586m P1
DIST S H V 1 SHV2 0SET
