Foif RTS680 Series User Manual

104
22.7 Connect PC via USB port
TS680 is equipped with USB port, you can connect it with PC for data transferring.
【Procedure of USB port connecting】
1. Select [
MEM] in the status mode to enter into
memory management.
2. Select “
5.USB” to enter USB port connecting
screen.
3. Connect instrument and PC via USB cable, TS680
will display “U FUNCTION Stop Press ESC”.
It means the TS680 is connected with PC already.
Press [ESC] to disconnect them, and the instrument
bact to previous menu.
For more information to see the Help file of
FOIFExchane on chapter “2.2 Data transfer via USB
slave port”.
Memory
1.JOB
2.Known data
3.Code
4.Storage Media Select
5.USB
U FUNCTION
Plug the USB
Exit Press ESC
U FUNCTION
Stop Press ESC
Memory
1.JOB
2.Known data
3.Code
4.Storage Media Select
5.USB
