20.3 Input Road Vertical Elements
Road vertical elements is confirmed by some intersection points, you should input same
parameters for the intersection points, including station, height, and length from this
intersection point to next intersection point.
20.3.1 Input Vertical Road Element.
1. Make sure the instrument is in Road Define menu,
select 2.Vertical Curve to vertical elements editing
menu.
Here:
Press F1:[FIST] key, the cursor will move to the first
element.
Press F2:[LAST] key, the cursor will move to the last
element.
Press F3:[Del] key to delete the selected element.
Press F4:[ADD] key to add a new vertical element.
2. Press F4 to display Vertical road element inputting
menu. Input the parameter for vertical element.
Press F4:[ENT] key to confirm.
VCurve/Element
STATION 0.000
Ht. 600.000
Lengh 200
ENT
StartPile Height
FIST LAST DEL ADD
Road Define
1.Horizontal Curve
2.Vertical curve
3.Road Calculation
