Foif RTS680 Series User Manual

42
3. Pt#: Known point data saved in the active JOB or in
the coordinate search JOB.
Occ./Coord: Coordinate data saved in the active
JOB or in the coordinate search JOB.
4. Select the first point in the list and press key {
ENT}
to set.
The selected point is set as “Pt-01”.
5. Repeat steps 2 and 4 till all points are selected.
Make sure read the points clockwise or
anticlockwise.
6. Press F2: [
CALC], and the calculated area will
display. Press F4: [
OK] to escape.
01:O1
02:Pt1
03:C1
04:Pt2
05:
06:
07:
READ CALC
Area Calculation
Pt: 4
Area m2
ha
0OK0
Occ.
Pt#
Coord
Pt#
Pt#
Pt#
Pt#
↑↓.P T O P LAST SRCH
O1
Pt1
C1
Pt2
Pt3
Pt4
Pt5
